| Power | |
|---|---|
| Capacity | • 8S Model: 8x 370 Farads Supercapacitors • 16S Model: 16x 370 Farads Supercapacitors |
| Input Connector | 3-pin Terminal Block (V+, GND, IGN IN) |
| Input Voltage | 12 ~ 35 VDC |
| Output Connector | 3-pin Terminal Block (V+, GND) |
| Output Power | • 8S Model: Max.100W output • 16S Model: Max. 200W output |
| Output Voltage | Charge mode: DC IN Voltage bypass (DC OUT = DC IN) Discharge mode: 12V or 24V Caution: • To use output voltage 24V DC, ECO-1000 input voltage must be 24V- 35V • Different voltage input/output can damage the systems. Ensure ECO-1000 Voltage Out setting matches the voltage input of external system. • For example, If the external system has a fixed voltage of 12V DC IN, the ECO-1000 must be configured for 12V DC OUT. |
| Charging Mode | Quick and Normal Charging |
| Power Ignition | Power Ignition Management |
| Power Protection | OVP (Over Voltage Protection) OCP (Over Current Protection) Reverse Protection |
| I/O | |
| COM | 1x RS-232 |
| DIO | 2 in / 2 out |
| USB | 1x USB Type A |
| Others | 1x Remote Power On/Off 1x Smart Mode Switch 1x Mode Reset Switch |
| Environment | |
| Operating Temperature | -20°C to 55°C |
| Storage Temperature | -30°C to 85°C |
| Relative Humidity | 10% to 95% (non-condensing) |
| Certification | CE, FCC Class A, UL 62368-1 Ed. 3 EMC Conformity with EN50155, EN50121-3-2 |
| Vibration | 5 Grms, 5 - 500 Hz, 0.5 hr/axis |
| Shock | 20G, half sine, 11ms |
| Physical | |
| Dimensions | 100 (W) x 192 (D) x 192 (H) mm |
| Weights | ECO-1000-8S-LCM: 2 KG ECO-1000-16S-LCM: 2.6 KG |
| Construction | Heavy Duty Metal |
| Mounting Options | Wall Mounting, DIN Rail Mounting (Optional) |
